2 Service and Maintenance
118 Keysight U3606B Service Guide
10 Remove the two screws holding the front panel with a Phillips (+) screwdriver.
11 You can now pry the side of the front panel from the chassis and remove it.
Front panel disassembly
12 Loosen the two captive screws with a Phillips (+) screwdriver and remove the
keypad and display assembly.
