17
MODEL #SE25 – 2,500LB (1134KG) WINCH
SPECIfICATIONS
Parts List
# Part Number Description Qty
1 MOTOR-25-BL Motor Assembly 1
2 HW-0002-B Screw M6 x 20 Socket 4
3 HW-0003-B Washer Ø6 6
4 WP-0005-B Tie Bar Ø10 x 85 2
5 WP-0006 Bushing, Shaft 1
6 WP-0007 Shaft, Splined 1
7 WP-0025 Set Screw M5 x 8 1
8 WP-0004 Drum, Steel, Standard 1
9 SYN19-S50
Cable, Synthetic,
3/16" x 50ft
1
10 WP-0009 Bushing, Drum, Rear 1
11 WP-0010 Washer, Thrust, Front 1
12 WP-0011 Gear Ring, Output 1
13 WP-0012 Gear Carrier Asm 1
14 HW-0004 Circlip Ø15 1
15 WP-0013 Spring, Clutch 1
16 WP-0014 Clutch Housing Cover 1
17 HW-0005-B Screw M6 x 70 Socket 2
18 WP-0015 Bearing 16002 Sealed 1
19 WP-0001 Clutch Cap 1
20 HW-0006-B Washer Ø6 Lock 1
21 HW-0007-B Screw M6 x 16 Phillips 1
22 WP-0016 Bushing, Axis Support 1
23 WP-0017 Bearing 6002 Sealed 1
24 WP-0018 Bushing, Clutch 1
25 WP-0019 Washer, Above Clutch 1
26 WP-0020 Cam, Clutch Gear 1
27 WP-0021 Gear Housing 1
28 WP-0022 Gear Ring 1
29 WP-0024 Gasket 1
30 WP-0023 Bushing, Motor 1
31 100495 Bracket, Fairlead, Standard 1
32 SE-RF Roller Fairlead, Stealth 1
33 WP-0030-BLK Hand Saver Strap, Black 1
34 ATV-CONT Contactor 1
35 ATV-MR Switch, Mini-Rocker 1
36
SE-WIRES-
ATV-WIN
Wiring, Winch, ATV 1
36.1 WP-0092 Terminal Protector 4
37
SE-WIRES-
ATV-BAT
Wiring, Battery, ATV 1
37.1 WP-0092 Terminal Protector 4
# Part Number Description Qty
38 SE-HOOK Clevis Hook, 1/4" 1
39 ATV-SCHS Split Cable Hook Stopper 1
40 SE-A-CAPKIT Motor End Cap Assembly 1
41 ATV-RPS
Protective Sheath,
Replacment
1
42 HK-500 Hardware Kit, Black 1
42.01
HW-0001 Wire Tap 2
42.02
HW-0014 Nut M6 Nylock 4
42.03
HW-0006 Washer Ø6 Lock 4
42.04
HW-0003 Washer Ø6 4
42.05
HW-0013 Bolt M6 x 25 4
42.06
HW-0015 Bolt M6 x 20 2
42.07
HW-0010 Bolt M10 x 20 2
42.08
HW-0011 Washer Ø10 Lock 2
42.09
HW-0012 Nut M10 Nylock 2
42.10
HW-0016 Washer Ø8 8
42.11
HW-0009 Washer Ø8 Lock 4
42.12
HW-0008 Bolt M8 x 25 4
42.13
HW-0018 Bolt M8 x 20 4
42.14
HW-0017 Bolt M8 x 30 4
To Next Page
