Quad Camera DVR
20
5.2 Stop Recording
Press the STOP button to stop recording, if there is a system password, this will need
to be entered to allow the recording process to stop.
5.3 Force Record Mode
If the DVR is not set to record because the schedule has been set to “-“ for the current
time, you can force the system to record by pressing and holding the ● REC record
button for more than 3 seconds. To stop the system from recording in forced mode,
press the STOP button.
5.4 Recording Length
The table below give the estimated record time in hours based on a 250GB Hard Drive
recording in Quad Mode.
Format Quality Frame Rate 30 15 7 1
HIGH 20 116 234 502 3496
NORMAL 15 156 310 666 4660
NTSC
LOW 12 194 388 832 5826
Format Quality Frame Rate 25 12 6 1
HIGH 20 140 292 582 3496
NORMAL 15 186 388 776 4660
PAL
LOW 12 234 486 970 5826
