Assemble units as described herein only. To do otherwise
may result in instability. All screws, nuts and bolts must be
tightened securely and must be checked periodically after
assembly. Failure to assemble properly, or to secure parts
may result in assembly failure and personal injury.
5
Balance
®
Overhead Cabinet
Assembly Instructions
Load Bar Mounted Overhead Units
1. To hang overhead units on a load bar,
rotate the bottom of the overhead unit
out approximately 30° and hook the
load bar mounting bracket onto the
top of the load bar. Rotate overhead
down until unit is secured in place
(Figure 4).
Note: Use the same procedure for
installing overhead units to load bars
on standard walls as with load bars
mounted to panel walls.
load bar
mounting bracket
load bar
load bar mounted
overhead unit
