KI CB - Table Operation; Adjust Height and Tension

Assemble units as described herein only. To do otherwise
may result in instability. All screws, nuts and bolts must be
tightened securely and must be checked periodically after
assembly. Failure to assemble properly, or to secure parts
may result in assembly failure and personal injury.
1330 Bellevue Street • P.O. Box 8100 • Green Bay, WI 54308-8100 • Tel 1-800-424-2432 • www.ki.com
© 2017 Krueger International, Inc. All Rights Reserved • Code KI-62484R4/KI/PDF/0817
Table Operation
Note: When adjusting the table up
or down, always make sure area is
cleared of any obstructions or pinch
points.
1. The table height can be adjusted
by pulling the release lever toward
you with one hand and using the
opposite hand to raise or lower the
table (Figure 5).
Warning: Table may raise up or
fall downward when release lever is
pulled. It is designed to be balanced
when the lifted weight is at the mid
point of load rating.
2. The cable tension has been preset at
factory, but can be adjusted for the
following:
• If table does not lock into place
when release lever is released,
turn cable adjustment nut in
1
/
2
turn and recheck.
• If table stays locked in one place
or adjusts slowly, turn cable
adjustment nut out
1
/
2
turn and
recheck (Figure 5).
WorkUp Adjustable Table
®
- Model CB
Assembly Instructions
