Killbros 690 - Power Train Components

23
Power Train Components
ITEM
1
2
3
4
5
6
7
8
9
10
11
12
13
14
PART NO.
9394-010
9404-025
94119
9405-088
102000
102555
9389-105
101958
105308
9398-019
9405-100
9390-122
103592
103570
DESCRIPTION
1/2” Hex Nut
1/2” Lockwasher
1/8” Grease Fitting, 90 Deg.
1/2” Washer
Bearing, 1-1/4” Pillow Block
1-1/4” Bearing Insert
1/2” x 2” Bolt
Key, 5/16” x 5/16” x 2-1/2”
Mounting Plate
5/8” Nylon Locknut
5/8” Flat Washer
5/8” x 1-1/2” Gr.5 Bolt
Push Pin Set
8mm Grease Fitting
OM02509
ITEM
15
16
17
18
19
20
21
22
23
24
25
26
PART NO.
103544
9389-101
103412
103541
103542
103543
103415
101954
103517
103540
103539
103534
105310
DESCRIPTION
Snap Ring
1/2” x 1” Bolt
Gear Box
1-3/8”-6, Outer Yoke
Cross Journal Ass’y
1-1/4”-5/16” Keyway Yoke
Universal Joint
1-1/4” Dia. x 8ft. Drive Shaft
Clean Out Door
Rear P.T.O. Shaft w/ Slip Clutch
Front P.T.O. Shaft, 1-3/8”-21
Front P.T.O. Shaft, 1-3/4”-20
Gear Box Cover
SEE PG. 24
SEE DIAGRAM
PG. 23
