Killbros 690 - Axle;Hub Components

26
Axle/Hub Components
ITEM
1
2
3
4
5
6
7
8
9
10
12
13
14
15
16
17
18
19
ITEM
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
PART NO.
101033
92734
92733
92457
93333
101042
92458
92461
92471
92463
9393-024
9391-059
9389-026
101041
92748
92749
92413
92415
104026
9398-019
9390-135
104220
104235
104236
PART NO.
100851
100747
100858
92457
93333
100849
92458
100857
92472
100746
100855
9928
91299-065
9389-026
92465
92416
92417
104022
9398-019
9390-138
104035
104382
DESCRIPTION
3” Seal (CR30087)
2-1/2” Bearing (39585)
2-1/2” Cup (8-414799)
Hub Stud (3/4”-16 x 2 1/2”)
Hub Stud (3/4”-16 x 3 1/2”)
Hub Ass’y w/Cups & Studs
Hub Nut (3/4”-16 Flange)
1-3/4” Cup (453A)
Spindle Washer (1-1/4”)
1-3/4” Bearing (460)
Spindle Nut (1-1/4”-12)
1/4” x 2” Cotter Pin
5/16” x 1/2” Bolt
Hub Cap
16 x 38 Wheel
18 x 36 Wheel
20 x 26 Wheel
21 x 32 Wheel
3-3/8” Dia. Spindle
5/8” Nylon Locknut
5/8” x 5-1/2” HCS
102” Axle
120” Axle
144” Axle
DESCRIPTION
4-3/8” Seal (CR43771)
3.54” Bearing (HM218248)
3.54” Cup (HM218210)
Hub Stud (3/4”-16 x 2 1/2”)
Hub Stud (3/4”-16 x 3 1/2”)
Hub Ass’y w/Cups & Studs
Hub Nut (3/4”-16 Flange)
2-5/8” Cup (HM212010)
2” Spindle Washer
2-5/8” Bearing (HM212049)
Spindle Nut (2”-12)
3/8” Rev. Locknut
3/8” x 3-1/2” Gr.8 Bolt
5/16” x 1/2” Bolt
Hub Cap
21 x 32 Wheel
27 x 32 Wheel
4-1/2” Dia. Spindle
5/8” Nylon Locknut
5/8” x 7” Gr.5 HCS
120” Axle
144” Axle
590
690
