30
1200 HLX+ Dimensions
2400 HLX+ Length 19.8 ± 0.08 in (505 ± 2 mm)
2400 HLX+ Weight 59.5 lb (27 kg)
3600 HLX+ Height 9.25 ± .04 in (235 ± 1mm)
3600 HLX+ Width 11.02 in (280 mm)
3600 HLX+ Length 20.5 in (520 mm)
3600 HLX+ Weight 88.2 lb (40 kg)
Terminals
Stainless Steel M8 - 1.25 x 16 mm Bolts. In all models,
the terminals extend 1mm above the case.
Terminal torque
Tighten the terminal bolts to between 7.38 and 8.11 ft-
lbs (88.51 to 97.36 in-lbs OR 10 to 11 nm)
