19
OPERATING THE SNOWBLOWER
a) Make sure the snowblower is clear of snow
before engaging the clutch.
b) Make sure that the auger and impeller operate
freely.
c) Start the snowblower engine.
d) Before engaging the snowblower drive, always
have the engine running at medium R.P.M.
e) Operate the snowblower at maximum engine
R.P.M.
IMPORTANT: USE FULL ENGINE R.P.M. WHEN
REMOVING WET, STICKY SNOW. LOW R.P.M.
POWER WILL TEND TO PLUG THE CHUTE.
CONTROLS
CHUTE ROTATION
The chute rotation handle is located to the left of handle
bars. Turning the handle in a clockwise direction, the
discharge chute will turn in a clockwise direction or vice
versa.
CHUTE DEFLECTOR
Set the angle of the deflector according to the distance
the snow must be blown and to prevent property
damage. To change the deflector angle, loosen the two
deflector knobs & adjust the deflector to the appropriate
angle and retighten the two knobs.
RAISING AND LOWERING THE SNOWBLOWER:
Use the winch switch control to raise and lower the
snowblower.
ENGAGING AND DISENGAGING THE
SNOWBLOWER:
Engage the snowblower when the engine is running
at medium R.P.M. To engage, pull the clutch lever
towards the back and to disengage, move the lever
forward.
OPERATION
REMOVING SNOW
When removing snow, do not use the snowblower as
a dozer blade to push snow. Allow snowblower to
ingest snow at its own speed. If the speed of your
A.T.V. is too fast, the snowblower may become
overloaded and plug. For best results, raise the
snowblower and remove a top layer of snow. A
second pass with the snowblower will remove the
remaining snow.
7
WARNING
7
Read the vehicle's owner’s manual carefully. Be
thoroughly familiar with the controls & proper
use of the attachment. Know how to stop the unit
& disengage the controls quickly
.
7
WARNING
7
-Do not attempt to clear plugged chute, auger or
fan of snow while the snowblower's engine is
running.
-Disengage snowblower.
-Lower snowblower onto ground.
-Set the parking brake.
-Stop engine, remove the ignition key, disconnect
the wire from spark plug(s) and keep away from
spark plug(s) to prevent accidental starting.
-Make sure all moving parts have stopped.
-Do not use hand to unplug chute.
-Use a 36’’ (924 mm.) minimum length stick or
board.
7
WARNING
7
TO PREVENT INJURIES AND FOR MORE
TRACTION WHEN USING SNOWBLOWER:
-Do not drive faster than 3 km/hr (2 m/hr) with
snowblower on the ground.
-Do not drive faster than 10 km/hr (6 m/hr) with
the snowblower in raised position.
-Do not operate on a slope greater than 10°.
-vehicle manufacturer approved tire chains are
required.
