Kinco FV20 User Manual

Chapter 6 List of Parameters
53
Chapter 6 List of Parameters
FV20 identified by
The parameter descriptions are listed in the tables below.
Table 6-1 Descriptions of Function Code Parameter Structure Table
No. Name Description
1 Function code The number of function code
2 Name The name of function code
3 Setting range The setting range of parameters.
4 Unit The minimum unit of the setting value of parameters.
5 Factory setting The setting value of parameters after the product is delivered
6 Modification
modified.
O Denotes the parameters can be modified during operation or at STOP state;
Denotes the parameters cannot be modified during operating;
Denotes the parameters are actually detected and cannot be revised;
Denotes the parameters are defaulted by factory and cannot be modified ;
(When you try to modify some parameters, the system will check their modification property
automatically to avoid mis-modification.)
Note:
1 Parameter settings are expressed in decimal (DEC) and hexadecimal (HEX). If the parameter is expresse
d in
hexadecimal, the bits are independent to each other.The value of the bits can be 0 F.
2
the factory settings. But the actual detected or recorded parameters cannot be initialized;
It is defaulted that no parameters except A0.03 are allowed changing. If you need change them,please
first
set b4.02(parameter write-in protection) from 1 to 0.
Table 6-2 List of Parameters
Function
code
Name Descriptions Unit
Factory
setting
Modif
.
Setting
range
Group A0.Basic operating parameters
A0.00 User password 0: No password protection.
Others: Password protection.
1 0 O 0 FFFF
A0.01 Control mode LED Unit s place: Motor 1 control mode
0: Vector c ontrol without PG
1: Vector control with PG
2: V/F control without PG
3: V/F control with PG
1 2 X 0 2
