Chapter 6 List of Parameters
58
Function
code
Name Descriptions Unit
Factory
setting
Modif
.
Setting
range
A3.15 Reference of inflection
point 2 of curve 4
A3.17 A3.13 0.01% 100.00% O 0 11000
A3.16 Actual value
corresponding to the Min
reference of inflection
point 2 of curve 4
The same as A3.02 0.01% 100.00% O 0 10000
A3.17 Reference of Inflection
point 1 of curve 4
A3.19 A3.15 0.01% 0.00% O 0 11000
A3.18 Actual value
corresponding to the Min
reference of inflection
point 1 of curve 4
The same as A3.02 0.01% 0.00% O 0 10000
A3.19 Min reference of curve 4 0.0% A3.17 0.01% 0.00% O 0 11000
A3.20 Actual value
Corresponding to the Min
reference of curve 4
The same as A3.02 0.01% 0.00% O 0 10000
A3.21 Characteristic selection of
curve
: Characteristic choice
of curve 1
0: set 0 Hz when frequency < 0 Hz
1: symmetrical about origin
2: absolute value
: Characteristic choice
of curve 2
0: set 0 Hz when frequency < 0 Hz
1: symmetrical about origin
2: absolute value
: Characteristic
choice of curve 3
0: set 0 Hz when frequency < 0 Hz
1: symmetrical about origin
2: absolute value
: Characteristic
choice of curve 4
0: set 0 Hz when frequency < 0 Hz
1: symmetrical about origin
2: absolute value
1 0000 O 0000
2222H
0000
Group A4.Acc/Dec parameters
A4.00 Acc/Dec mode 0: Linear Acc/Dec
1: S curve
1 0 X 0 1
A4.01 Acc time 2 0.0 6000.0 0.1s 20.0s O 0 60000
A4.02 Dec time 2 0.0 6000.0 0.1s 20.0s O 0 60000
A4.03 Acc time 3 0.0 6000.0 0.1s 20.0s O 0 60000
A4.04 Dec time 3 0.0 6000.0 0.1s 20.0s O 0 60000
A4.05 Acc time 4 0.0 6000.0 0.1s 20.0s O 0 60000
A4.06 Dec time 4 0.0 6000.0 0.1s 20.0s O 0 60000
