Chapter 6 List of Parameters
63
Function
code
Name Descriptions Unit
Factory
setting
Modif
.
Setting
range
13: PLC running cycle complete signal
14: Limit of swing frequency
upper/lower limit
15: Drive ready (RDY)
16: Drive fault
17: Switching signal of host
18: Reserved
19: Torque limiting
20: Drive running forward/reverse
21: Timer 1 end
22: Timer 2 end
23: Setting counter reach
24: Middle counter reach
35
:
Motor 1 and motor 2 indicating
terminals
Other: Reserved
A6.15 Reserved - 1 0 O 0 65535
A6.16 Output functions of relay
R1
The same as A6.14 1 16 X 0 50
A6.17 Reserved - 1 0 O 0 65535
A6.18 Delay of relay R1 0.1 10.0s 0.1s 0.1 O 1 100
A6.19 Reserved - 1 0 O 1 65355
A6.20
and negative logic
Binary setting:
0: Terminal is enabled if it is
connected to Corresponding common
terminal, and disabled if it is
disconnected.
1: Terminal is disabled if it is
connected tocorresponding common
terminal, and enabled is it is
disconnected.
:
BIT0 BIT1.Y1 R1
:
BIT0.D0
1 0 O 0 1FH
A6.21 Frequency arriving signal
(FAR)
0.00 300.00Hz 0.01Hz 2.50Hz O 0 30000
A6.22 FDT1 level 0.00 300.00Hz 0.01Hz 50.00Hz O 0 30000
A6.23 FDT1 lag 0.00 300.00Hz 0.01Hz 1.00Hz O 0 30000
A6.24 FDT2 level 0.00 300.00Hz 0.01Hz 25.00Hz O 0 30000
A6.25 FDT2 lag 0.00 300.00Hz 0.01Hz 1.00Hz O 0 30000
A6.26 Virtual terminal setting Binary setting
0: Disable
1: Enable
1 00 O 0 FFH
