Chapter 6 List of Parameters
64
Function
code
Name Descriptions Unit
Factory
setting
Modif
.
Setting
range
:
BIT0 BIT3.X1 X4
:
BIT0 BIT1.X5 X6
A6.27 Y1 terminal output 0 50: D0 is used as Y terminal output.
51 88: D0 function
0: Running signal(RUN)
1: frequency arriving signal(FAR)
2: frequency detection threshold
(FDT1)
3: frequency detection threshold
(FDT2)
4: overload signal(OL)
5: low voltage signal(LU)
6: external fault signal(EXT)
7: frequency high limit(FHL)
8: frequency low limit(FLL)
9: zero-speed running
10: Terminal X1(Reserved)
11: Terminal X2(Reserved)
12: PLC running step complete signal
13: PLC running cycle complete signal
14: Limit of swing frequency
upper/lower limit
15: Drive ready (RDY)
16: Drive fault
17: Switching signal of host
18: Reserved
19: Torque limiting
20: Drive running forward/reverse
21 50: Reserved
51: Output frequency
(0 Max. output frequency)
52: Preset frequency
(0 Max. output frequency)
53: Preset frequency (After
Acc/Dec)(0 Max. output frequency)
54: Motor speed(0 Max. speed)
55: Output current(0 2*Iei)
56: Output current(0 2*Iem)
57: Output torque(0 3*Tem)
58: Output power(0 2*Pe)
59: Output voltage(0 1.2*Ve)
60: Bus voltage(0 800V)
61: AI1
62: AI2
1 0 O 0 88
