Kinco FV20 - Page 28

Chapter 6 List of Parameters
66
Function
code
Name Descriptions Unit
Factory
setting
Modif
.
Setting
range
A6.40 AI1 gain 0.00% 200% 0.01% 100% O 1 20000
A6.41 AI2 gain 0.00% 200% 0.01% 100% O 1 20000
A6.42 Keyboard potentiometer
gain
0.00% 200% 0.01% 100% O 1 20000
A6.43
A6.45
Reserved - 1 0 O 0 65535
A6.46 Timer 1 setting value 0.00 10.0s 0.1s 0.0 O 0 100
A6.47 Timer 2 setting value 0 100s 1s 0 O 0 100
A6.48 Counter target value 0 65535 1 100 O 0 65535
A6.49 Counter middle value 0 65535 1 50 O 0 65535
A6.50 Multi speed terminal
switching time
0 500 1 0 O 0 65535
A6.51
A6.60
Reserved 1 0 O 0 65535
Group A7.PG Parameters
A7.00 PG type 0: ABZ incremental type
1: UVW incremental type
2: Cosine type
3: Reserved.
1 0 O 0 3
A7.01 Number of pulses per
revolution of PG
1 10000 1 2048 O 1 10000
A7.02 Direction of PG 0: A phase lead B phase
1: B phase lead A phase
1 0 X 0 1
A7.03 Encoder signal filter
number
:
0 9 high-speed filter
:
0 9 low-speed filter
1 30H O 0 99H
A7.04 PG disconnection
detecting time
0.0: Disable
0.1 10.0
0.1s 0.0 O 0 100
A7.05 Reduction rate of
motor and encoder
0.001 65.535 0.001 1 O 0 65535
Group A8.Fault parameters
A8.00 Protective action of relay : Action selection
forunder-voltage fault indication.
0: Disable;
1: Enable
: Action selection for
auto reset interval fault indication.
0: Disable
1: Enable
: Selection for
fault locked function.
0: Disable
1 0000 X 0 1111H
