Low Pressure Switch:
The low pressure switch is used to shut the
system down if an inadequate feed pressure is
present.
The set point for the pressure switch is 1 bar.
The switch is located between the inlet valve
and pump.
13
By-Pass Solenoid Valve:
Another exclusive feature of the RO-Compact
series Is an automatic by-pass valve. As a
normally open valve, the valve allows inlet water
to be bypassed should the permeate reservoir
become exhausted.
This assures the operator equipment or process
will not be damaged by a lack of water. Provided
there is water in the permeate tank, the by-pass
valve instantly closes as soon as the flow switch
is activated by the need for water. (This valve
is not included with the “U” versions of these
systems.
These units have no bypass. A pressure switch
is substituted for the bypass to signal the
operation of the pressurization pump.)
14
Non-Return Valve:
This nickel plated valve prohibits permeate
water from back flowing to the inlet tap.
15
Flow Switch:
This electric contact has a sensitivity to activate
at 1 l/m.
At this contact, the unit shuts the bypass
valve, provided there is water in the permeate
reservoir, and activates the distribution pump.
Fittings:
The following fittings are used in the
RO-Compact Series.
(Despite appearances, they have the same part
number and function in the same way.)
Part 170451:
Part 170449:
Part 170448:
Part 170463:
Part 521122:
