RO Compact Series Technical Manual
20
Installation
Pre-Installation Review:
Before beginning the installation of the RO-
Compact, determine the system configuration
to be installed and components that have been
ordered. Please refer to the RO-Compact series
system specification sheet which will specify
the required components.
A thorough review of the customer’s facilities
is also recommended. Pay particular attention
to the critical operating data which could aect
the operation of the system.
Water Pressure:
Water pressure to the RO-Compact
system has an eect on the maximum
flow through the system. The system will
not operate if the inlet pressure fluctuates
below a dynamic pressure of 1 bar.
This minimum pressure must be maintained
to the system at all times. Should the pressure
fluctuate below this level, a booster pump may
be required.
Temperature:
The ambient temperature must be
maintained above 2°C.
Freezing temperatures will cause damage to the
equipment and void all warranties.
Inlet water temperature must be
maintained between 5°C and 25°C.
This is necessary to prevent damage to the
system’s membrane.
System Location:
The unit must be
installed indoors.
Failure to comply with this requirement can
cause significant damage to the system and will
create a safety concern.
The unit must be placed on a frost-free, even
surface.
The floor must be able to withstand the load of
the system when filled with water:
76 kg RO-Compact 1
125 kg RO-Compact 2
138 kg RO-Compact 3
The unit must be installed in a room
with open floor drains.
Do not block ventilation grids at base
of system.
Electrical Connection:
Electrical connection must be made in
accordance with local regulations.
The following process has been developed to assist you with
the installation of your RO-Compact product.
The installation of this RO should be performed by a qualified service person with an
understanding of local and regional codes that may aect the installation requirements.
