www.kinetico.eu
19
Level Switch:
A level Switch is built into the permeate reservoir.
System Controller:
The Compact Series is operated by a microprocessor controller, designed to enhance the
operation of the system when operating with dishwasher machines.
The mid and high level switches are used to
measure permeate volume. With a set distance
between these floats, the circuit board is designed
to time the refill between these two points, and
display the calculated batch flow rate.
Each input is a low voltage signal processed
internally by the controller. Each output is
processed at 230 VAC, and controlled by the
system’s input. All of this adds to the safety of
the system’s operation.
The following components are operated by
the controller:
• Inlet Pump
• Inlet Solenoid Valve
• By-pass Solenoid Valve
• Distribution Pump
Please note: The control Box has no serviceable
components and should not be opened, unless
by a trained electrician.
Permeate Flow Rate
The permeate flow rate will be displayed after the
completion of each batch cycle (when the unit
refills with water between the mid and high levels,
without calling for water). Three dashes will be
displayed (- - -), when the refill cycle is interrupted
by the distribution pump calling for water.
Power
A number or three dashes, will indicate when
power is energized to the system.
Membrane Alarm
The Membrane Alarm “ERR” will activate if a
product cycle is lower than the alarm set point. It
will flash if the production cycle is above the alarm
set point. In each case, service is recommended.
No Water Alarm
The No Water Alarm will activate when feed
pressure to the system is below minimum. It will
flash when the cabinet is empty.
