21
Unpacking:
1. Release the box from the pallet.
2. Lift the box from the pallet. It will slide
straight up and uncover the RO-Compact.
3. Discard packing material and set aside the
additional 2 meters of 10 mm tubing system
manual.
4. Inspect the unit for possible shipping
damage. Including cabinet damage, broken
fittings, dents or scratches.
Cabinet Positioning:
The RO-Compact series has been specifically
designed to be moved and positioned
conveniently under a standard level counter.
Caution should be used whenever
moving the equipment.
Move the RO cabinet to the location of the
installation.
You must take into consideration that the hood
can be removed for easy access. Either a height
clearance of 25cm must be left or it must be
made possible that the unit can be pulled out
for servicing.
Colour codes on the wires:
The unit must be connected to positive + neutral
+ ground.
Blue wire: Neutral
Brown wire: Positive
Yellow/green wire: Ground
RO-Compact 1
Dimensions
d x w x h/cm
55 x 25 x 76
Required Clearance for
Removing Cover cm
101
Weight (dry) kg 43
Voltage Volts 230
Frequency Hz 50
Amperage Amps 10
Power kw 1,1
RO-Compact 2
Dimensions
d x w x h/cm
58 x 46 x 70
Required Clearance for
Removing Cover cm
88
Weight (dry) kg 56
Voltage Volts 230
Frequency Hz 50
Amperage Amps 10
Power kw 1,1
RO-Compact 3
Dimensions
d x w x h/cm
58 x 46 x 70
Required Clearance for
Removing Cover cm
88
Weight (dry) kg 71
Voltage Volts 230
Frequency Hz 50
Amperage Amps 10
Power kw 1,7
