Definition of terms:
Inlet Pressure Switch - PS1
(Normally Open)
A normally open (NO) contact pressure switch
with a set point of 1 bar (14.5 psi) is located on
the feed water inlet. Below 1 bar the contact
is Open, not allowing power to flow through
the device. Above 1 bar the contact is closed,
allowing power to flow through the device.
High Level Float Switch - LSH
(Normally Open)
A normally open (NO) contact float switch
located in the RO permeate reservoir, above
the mid level float near the top of the reservoir.
Below this level the contact is open, not allowing
power to flow through the device. Above this
level the contact is closed, allowing power to
flow through the device.
Mid Level Float Switch - LSM
(Normally Open)
A normally open (NO) contact float switch
located in the RO permeate reservoir below the
high level float in the middle of the reservoir.
Below this level the contact is open, not allowing
power to flow through the device. Above this
level the contact is closed, allowing power to
flow through the device.
Low Level Float Switch - LSL
(Normally Open)
A normally open (NO) contact float switch
located in the RO permeate reservoir below the
mid level float near the bottom of the reservoir.
Below this level the contact is open, not allowing
power to flow through the device. Above this
level the contact is closed, allowing power to
flow through the device.
Flow Switch - FS1
(Normally Open)
A normally open (NO) contact flow switch
located on the permeate outlet to the users
equipment.
Bypass Solenoid Valve - MV2
(Normally Open)
This is a normally open (NO) 230VAC, 50/60 Hz
solenoid located on the line between the feed
water inlet connection and the permeate water
outlet connections. When energized with power,
the solenoid closes.
Feed Solenoid Valve - MV1
(Normally Closed)
This is a normally closed (NC) 230VAC, 50/60
Hz solenoid located on the line between the feed
water inlet and high pressure feed pump. When
energized with power, the solenoid valve opens.
High Pressure Feed Pump - P1
This is a 230VAC, 560W, 50 Hz, 4.2A single
phase rotary vane pump used to pressurize the
water from the feed water inlet connection to
the RO membrane.
Distribution Pump - P2
This pump is a 230VAC, 500W, 50Hz, 2.9A single
phase centrifugal pump, used to depressurise the
permeate water in the permeate reservoir and
send it to the permeate outlet connection.
