Kinetico Reverse Osmosis Compact Series User Manual

www.kinetico.eu
27
High Pressure Feed Pump - LMP1
Run Lamp
A lamp located on the circuit board to denote
when the high pressure feed pump (P1) is
energized.
Feed Solenoid Valve Lamp - LMP2
A lamp located on the circuit board to denote
when the feed solenoid valve (MV1) is energized.
Distribution Pump/Bypass - LMP3
Valve Lamp
A lamp located on the circuit board to denote
when the distribution pump (P2) and bypass
valve (MV2) are energized.
“No Water” Alarm Indicator - IND2
Lamp (Red)
A lamp located on the front of the enclosure, to
denote the inlet pressure condition is low. If the
lamp flashes it means there is no water in the
reservoir.
“Change Membrane” Alarm - IND3
Indicator Lamp (Yellow)
A lamp located on the front of the enclosure, to
denote the calculation made by the production
of RO water between the mid level and high
level is outside of the minimum and maximum
set points. If the production rate in l/ph is below
a minimum setting, the indicator lamp (IND3)
will be on constantly. If the production rate in
l/ph is above a maximum setting the indicator
lamp (IND3) will flash.
Display Screen - SCRN
A 3 digit display denotes the l/ph of water
produced by the RO Membranes (RO permeate
rate). This value is calculated by using a set volume
based on jumpers J2 and J3, and the time it takes
to fill the RO Permeate Reservoir between the
mid level and high level. The distribution pump P2
must not be on during this calculation time. This
calculated value is compared with a minimum and
maximum value to initiate a “change membrane”
alarm as described by IND3.
External Alarm Contact - CR1
This is a 5 amp relay contact with a common,
normally open contact. This can be used as a
dry contact closure for either the “No Water”
alarm or the “Change Membrane” alarm. If either
of these indicator lights are energized, then this
relay is also energized.
Outlet Pressure Switch - PS2
(Normally Closed)
A normally closed (NC) contact pressure switch
with a set point of 1.6 bar (36.25 psi) located
on the permeate water outlet. Below 1.6 bar the
contact is closed, allowing power to flow through
the device. Above 1.6 bar the contact is open, not
allowing power to flow through the device. This
device is used on no-bypass systems and is wired
in parallel with the flow switch FS1.
