Kinetico Reverse Osmosis Compact Series User Manual

www.kinetico.eu
39
Part Number Description Pieces
160001 Pump 1,000 l/ph - Brass 1
160005 Motor - 560w, 230v, 50Hz 1
170007 Pump - SS, 500w, 230v, 50Hz 1
170054 Cable Gland - M20 x 1,5 2
170403 Tube - Pu 12/10 Blue 0,5
170407 Tube - Pu 10/8 Nature 0,8
170451 Tee - 1/2” x ø12 Push In 1
170467 Mw-R6 Base Male - 12-1/2” 1
170470A Nipple ø 15mm x 1/2” bspp 1
170484 Elbow Insert 2
384806 Top Plate Compact 1 1
521310 Gasket - ¾” 1
660026 Reduction Ms - 1" x ½" 1
660045 Elbow - N/M ½” 1
660053 Hex Jam Nut - ¾” 1
660054B Hex Nipple - Bspp ¾” x Bspp 1” 1
660206 NON return valve “short” 1
RO-Compact 1 Parts:
The pumps
160001
170451
160467
170484
170403 170407
170007
660054B
521310
660053
660206
170470A
660045
384806
170054
660045
