Kinetico Reverse Osmosis Compact Series User Manual

www.kinetico.eu
61
RO-Compact 3 Parts:
Membrane and components
Part Number Description Pieces
160521 RO-Membrane - Compact Low 3-4021 3
170316 Level Switch - 66 litre 1
170401 Tube Pu - 12/8 Red (2 x 800mm) 2
170403 Tube Pu - 12/10 Blue (2 x 850mm) 2
170447 Flexible Elbow - ø12 x ½” 3
170448 Elbow - ø12 Push In 2
170455 Tee - 12mm Push In 1
170467 Base Male - ø12 x ½” 3
384831 Top Plate - RO-Compact 3 1
384904 Bottom Plate - RO-Compact 2 & 3 1
170316
170403
170401
160521
384831
170447
170448
170467
170455
384904
Plastic nut is included with the membrane.
6 x 3mm holes have to be drilled
(see picture).
