Kinetico Reverse Osmosis Compact Series User Manual

www.kinetico.eu
63
Part Number Description Pieces
170255 Non Return Valve - ½" 2
170261 Solenoid valve - NC ½” 1
170262 Solenoid valve - NO ½” 1
170265 Sirai Connector Plug 2
170270 Connector for Flow switch - 15mm 1
170307 Pressure Switch 1/8” (preset at 1 Bar) 1
170312 Hood for Pressure Switch 1
170446 LG 45° Male Elbow - 12 x ½" 2
170447 Twisting Elbow - ø12x½" 1
170462 Connector - ø12 x ½” Push In 1
660037 Nipple - ½”- ¾” N/N 1
660039 Y-Piece - ½” 1
660040 Nipple Pipe ½” x 25mm 1
660044 Tee - ½” 3
660045 Elbow - M/N ½” 3
660046 Elbow - N/N ½” 1
660048 Nipple - ½” 1
700062 Nipple PVC - ø12 x 1/8" 1
660056 Elbow - ½” (only used with no-bypass) 1
170312
660056
Plumbing without bypass
