RO Compact Series Technical Manual
68
Part Number Description Pieces
171077 Seal 3/8" 1
171084 Spring for Nozzle 2
190050 Mounting Box 1
190051 Terminal - Ground 4
190053 Terminal - Blue 5
190054 Terminal - Grey 5
190056 Deep Top Hat Punched 0,13
190061 Bottom frame with Rolls 1
380070 Outer box without Bottom 1
384736 Cabinet - RO 66 litre 1
384804-C2 Lid - RO-Compact 2 & 3, Black 1
384831 Top Plate - RO-Compact 3 1
384904 Bottom Plate - RO-Compact 2 & 3 1
400021 Non Return Valve 3/8" SS 1
521122 Wire Nut 2
521310 Seal 1
521466 Metric Threaded Cap - ¾" 2
651400 Prefilter - ¾" 1
660001 Red Short - ¾" x ½" 1
660026 Reduction MS - 1" x ½" 1
660027 Tee - 3/8" 1
660034 Elbow - N/M ¾" 1
660037 Nipple - ¾" x ½" 1
660039 Y-Piece - ½" M/N/M 1
660040 Nipple Pipe Brass - ½" x 22mm 1
660044 Tee - M/M/N ½" 3
660045 Elbow - M/N ½" 4
660046 Elbow - Nn ½" 1
660048 Nipple - ½" x 25mm 1
660053 Hex Jam Nut - ¾" 1
660054B Nipple for Check valve 1
660206 NON return valve “short” 1
700062 Nipple PVC - 12 x 1/8" 1
700902 PVC Hanger - 25mm with Safety Clip 1
700903 PVC Hanger - 32mm 3
