Kinetico Reverse Osmosis Compact Series - Terminal Block Wiring (RO-Compact 2 & 3); 230 V Main Cable Connections

www.kinetico.eu
75
N N N N N P
1
P
1
P
2
MV
2
L
230 V
P1 a
P1 b
MV 2
P2
RO-Compact 2:
RO-Compact 3:
to No.4
to No.7
to Fuse
to No.10
to No.4
to No.7
to Fuse
to No.10
to No.1
230V = Main cable
P1 (A,B) = High pressure pump
P2 = Transport pump
MV2 = Bypass solenoid
230V = Main cable
P1 (A,B) = High pressure pump
P2 = Transport pump
MV2 = Bypass solenoid
to No.1
