KING- M ETER speci ficat ion of WH527-LCD disp lay v1.0
7.User Setting
With display on，press and together>2s，enter into
normal setting, can choose mode by press
or ,the follow is setting indication：
○ SET code 1——wheel size
○ SET code 2——limited speed
○ SET code 3——brightness backlight
○ SET code 4——switch setting of British(Mp)/Metric(Km)
7.1 Wheel Size Setting
When the interface indicate SET code 1，press and <2s，
setting wheel size ，and press <2s to confirm the choice.
Settable wheel size ：16、18、20、22、24、26、700C、28、29. For ensure
the indication accuracy of speed and distance, the wheel size shown
on display is 26 inch by default.
Wheel size shown by default
