2. 搬運 Moving
outside is possible by moving control lever up and down)
壓扣式 By push-button
Mobil#10或同等級的產品 Mobil#10 or equivalent
強制潤滑 Automatic lubrication by oil pump
By adjusting screw or by control lever (Adjusting during operation from
外部調整，附粗調扳手，微調旋鈕
最大縮縫比 1 : 2.9，最小伸縫比 1 : 0.3
Max. normal differential ratio 1 : 2.9, max. Reverse differential ratio 1 : 0.3
For needles distance 5.6mm ; with spreader : 5.0mm with no spreader : 7.0mm
33mm
3 Needles : 4.8mm, 5.6mm, 6.4mm (2 Needles : 3.2mm, 4.0mm)
3針 : 4.8mm, 5.6mm, 6.4mm (2針 : 3.2mm, 4.0mm)
Schmetz or Organ UY128GAS No.65~No.90 ( 標準 Standard : No.70 )
1.4~3.6mm 相當於7~18針 / 每英吋 Stitch number : 7~18 stitch / inch
(4500 stitches / min for the machine with puller)
5500針 / 每分鐘 , Max. 5500 stitches / min
薄類,中厚類 General seaming of knitted material
ISO 406, 407, 602, 605
280mm
高速方筒型繃縫機 High speed cylinder bed interlock machine
CT 9000
潤滑油 Lubrication oil
潤滑方式 Lubrication
差動調整方式
Differential feed regulation
差動可調範圍
Differential ratio
進給調整方式 Feed regulation
Presser foot lift
壓腳提升量
針棒行程 Needle stroke
針距 Needle distance
進給可調範圍 Stitch length
縫針型號 Needle to be used
最大縫製速度 Sewing speed
適用範圍 Application
線跡型式 Stitch type
Circumference of cylinder bed
圓筒座周長
種類 Description
型式 Model
1. 規格 Specifications
當搬運機器時，請勿從下座布板蓋部位搬動。
！
外型尺寸 Dimensions 480mm (L) * 250mm (W) * 430mm (H)
重量 Weight 40.5 kg
針距為5.6mm時，有上飾縫勾針：5.0mm，無飾縫勾針：7.0mm
Do not hold the cloth plate cover when carrying the machine.
