V形M系列皮帶
M-type of V-belt
馬達
For table top type
皮帶下蓋
皮帶蓋
60 Hz50 Hz
4500
5000
5500
6000
6000
5500
5000
4500
machine for
s. p. m. Of
縫機轉速
馬達皮帶輪外圈直徑
Outside diameter of
motor pulley (mm)
85
90
100
105
110
120
pulley. Align when motor pulley shift to the left by pushing pedal.
position of motor so that the centers of motor pully and machine
C. Motor : Use clutch motor of 3-phase, 2-pole, 400 W(1/2HP). Fix the
B. Belt cover : Install belt as shown in the illustration.
clockwise and the motor belt tension can be pressed inward about
A. Belt : m type v belt and be sure that the motor turning direction is
the machine. Please do not exceed 80% of the ordinary speed.
speed is 5000 s.p.m. during the first 200 hours (or first month) of using
The maximum swing speed of this machine is 5500 s.p.m. and ordinary
。本機型適用馬達為3相2極400W(1/2馬力)離合馬達，踏板踩下
3-3. 馬達、皮帶與皮帶護蓋 Motor belt and belt cover
本機最高轉速可達5500針 / 每分鐘，一般多以5000針 / 每分鐘
來使用，在最初200小時(約1個月)請以80%的速度來使用，以
確保機器的使用壽命，傳動皮帶為V形M系列三角皮帶，掛上
20mm
僅限於上載式安裝
皮帶後請先確認皮帶的鬆緊度，由皮帶的中間輕壓約有20mm
的彈性，再確認皮帶的迴轉方向是否正確，最後裝上皮帶護蓋
啟動馬達時皮帶輪會向左移動，請將馬達安裝在皮帶輪與機器
皮帶輪同一中心線的位置上，下表列出皮帶輪徑與轉速的關係。
61mm
40°
10mm
5.5mm
裝置皮帶蓋如下圖所示
Install the belt cover as shown in the figure below.
固定皮帶下蓋在車板上（僅限於上載式安裝）
Fix the belt cover(lower) to the machine table.
(Only for table top type)
CT9000
Motor
Belt cover (Lower)
Belt cover
迴轉方向
Turning direction
20mm.
