6
-23MAINTENANCE
1. After loosening bolts from the left
and right side of the cabin roof and
removing the cover, separate the el-
ement from the filter.
2. Clean the filter and element using
compressed air.
(1) Bolt (2) Filter
CLEANING AIR FILTER
S43O646A
(1) Butterfly Bolt (2) Condenser
CLEANING AIR CONDITIONER
COOLER
Make sure to stop engine when
checking.
If cooler fan is blocked by dirt,
clean with a soft brush or cloth
using tab water.
!!
!!
!
CAUTION
S43O636A
REPLACING HYDRAULIC OIL
FILTER
1. Look at page 6-11.
Clean the filter using a com-
pressed air
Never use water, oil or thinner.
!!
!!
!
CAUTION
To Next Page
