4
-7DESCRIPTION OF OPERATING SYSTEM
ENGINE COOLANT TEMPERA-
TURE GAUGE
This indicates the coolant temperature.
If the engine is normal, the tempera-
ture indicator does not move after reach-
ing the safety zone.
If the gauge reaches the red
zone, immediately turn off the
engine and have it inspected at
your local KIOTI service facility
or dealer.
!!
!!
!
CAUTION
ENGINE SPEEDMETER/
HOURMETER INDICATOR
ENGINE SPEEDMETER
This indicates engine revolution num-
ber per minute.
HOURMETER INDICATOR
FUEL GAUGE
This indicates the remaining fuel.
F : Fuel is fully filled.
E : Replenish the fuel tank.
S43O408A S43O410AS43O409 A
This indicates the time as the rated
revolution number of the engine.
(1) Engine Speedmeter
(2) Hourmeter Indicator
(1) Fuel Gauge
