DM588 Service Manual
SN
Material NO
Material Name
Specifications
QTY
Component NO
7
2CC1-10-X7R500-1
02K
R multi-layer chip
capacitor
1005, 1000P±10%, 50V, X7R 76
C7,C11,C20,C25,C26,C398,C463,C94,C99,C105,
C108,C157,C383,C214,C231,C235,C239,C245,C
280,C282,C295,C297,C304,C330,C337,C339,C55
1,C49,C369,C372,C379,C389,C390,C396,C407,C
408,C409,C410,C411,C412,C438,C51,C62,C392,
C417,C420,C422,C431,C432,C481,C487,C494,C
501,C43,C305,C388,C397,C400,C405,C406,C434
,C446,C447,C513,C514,C515,C516,C517,C522,C
548,C464,C512,C520,C523,C524,C559
8
2CC1-10-X7R500-1
03K
R multi-layer chip
capacitor
1005, 10nF±10%, 50V, X7R 17
C21,C93,C97,C98,C178,C183,C218,C220,C232,C
233,C238,C253,C293,C471,C564,C579,C224
9
2CE1-VS250-101M
0607D
SMD aluminum
electrolytic capacitor
SMD-6.3x7.7mm, 100uF/25V 5 C69,C357,C65,C493,C495
10
1DR1-NSR1020M
W2T1G
SMD Schottky barrier
diode
NSR1020MW2T1G, lead free 1 D1
11 1DS1-DA2S10100L R SMD switch diode DA2S10100L 6 D2,D3,D38,D40,D12,D30
12 1DR1-SMCJ20A SMD diode
Transient voltage suppressor /
SMC/DO-214AB
1 D36
13
3FW1-42932-30232
0
R SMD fuse
(SC)429003/433003/466003, 3216,
3A/32V
1 F1
14 5FE1-BLM11A601S R SMD EMI filter
1608,
BLM11A601S/BLM18AG601S(0138-05)
11
FB1,FB4,FB12,FB27,FB28,FB47,FB52,FB49,L38,
L39,FB16
15 1IS1-MP2359
SMD switch power
supply IC
MP2359, 6PIN, 1.2A 24V, 1.4MHz,
TSOT-23-6
1 IC1
16
1IS1-XC6209B552
MR
SMD voltage regulator
IC
5.5V, SOT-23-5 encapsulation 1 IC3
17
1IS1-XC6209F502P
R
SMD voltage regulator
IC
XC6209F502PR, SOT-89-5, 5.0V 1 IC24
18
2LG1-VLS3012ET-
SMD power inductor
VLS3012ET-100M, 10uH+20%
5
L1,L64,L65,L62,L63
42
