DM588 Service Manual
SN
Material NO
Material Name
Specifications
QTY
Component NO
100M
3*3*1.2MM
19
1TF1-SSM3K15AF
S
R SMD field effect
transistor
SSM3K15AFS (D1) 3 Q10,Q11,Q20
20 1TF1-ST2301
R SMD field effect
transistor
ST2301A, SOT-23 3 Q17,Q23,Q102
21 1TT1-DTA144EE R SMD triode Digital triode DTA144EE-SMD 1 Q19
22 1TT1-DTC144EE R SMD triode Digital triode DTC144EE(26), SOT323 6 Q21,Q22,Q24,Q25,Q1,Q2
23
1TF1-IRFR9024NP
BF
Power MOSFET
IRFR9024NPBF, IRF, TO-252AA
encapsulation
1 Q27
24 2RS1-10-103J R chip resistor 1005, 10K±5% 38
R1,R223,R172,R173,R28,R32,R39,R51,R214,R77
,R109,R229,R175,R176,R177,R178,R231,R7,R9,
R291,R292,R293,R294,R315,R192,R195,R224,R
269,R298,R197,R200,R210,R230,R277,R278,R27
9,R322,R323
25 2RE1-10-6802 Precise SMD resistor 1005, 68K±1% 1 R3
26 2RE1-10-1602 Precise SMD resistor 1005, 16.2K±1% 1 R4
27 2RS1-10-102J R chip resistor 1005, 1K±5% 14
R5,R6,R8,R147,R212,R233,R258,R97,R144,R127
,R128,R182,R201,R199
28 2RS1-10-274J R chip resistor 1005, 270K±5% 1 R145
29 2RS1-10-203J R chip resistor 1005, 20K±5% 2 R146,R95
30 2RS1-10-471J R chip resistor 1005, 470Ω±5% 4 R154,R261,R263,R306
31 2RS1-10-104J R chip resistor 1005,100K±5% 16
R155,R217,R262,R264,R57,R58,R59,R94,R106,R
107,R115,R116,R307,R29,R228,R13
32 2RS1-10-822J R chip resistor 1005, 8.2K±5% 4 R218,R42,R55,R202
33 2RS1-10-123J R chip resistor 1005, 12K±5% 2 R221,R53
34 2RS1-10-472J R chip resistor 1005, 4.7K±5% 3 R232,R329,R56
35
2RS1-10-473J
R chip resistor
1005, 47K±5%
8
R234,R52,R119,R123,R226,R227,R153,R18
36 1IS1-LM2941S SMT IC
LM2941S/TO-236, 5-PIN, low-dropout
regulator, lead free
1 U200
