DM588 Service Manual
SN
Material NO
Material Name
Specifications
QTY
Component NO
37
2CC1-10-C0G500-5
R0C
R multi-layer chip
capacitor
1005, 5P±0.25P, 50V, C0G 4 C75,C145,C212,C229
38
2CC1-10-C0G500-1
01J
R multi-layer chip
capacitor
1005, 100P±5%, 50V, C0G 26
C76,C324,C325,C86,C89,C116,C131,C138,C174,
C189,C192,C546,C335,C336,C341,C342,C343,C
344,C345,C347,C353,C354,C394,C395,C429,C43
0
39
2CC1-10-C0G500-1
00D
R multi-layer chip
capacitor
1005, 10P±0.5P, 50V, C0G 4 C77,C144,C148,C299
40
2CC1-10-X7R160-1
04K
R multi-layer chip
capacitor
1005, 100nF±10%, 16V, X7R 85
C79,C74,C48,C73,C104,C110,C111,C126,C128,C
139,C141,C143,C152,C155,C156,C158,C159,C16
1,C262,C327,C234,C244,C249,C260,C264,C281,
C283,C294,C296,C298,C475,C332,C333,C334,C
340,C346,C349,C359,C437,C549,C550,C423,C42
4,C425,C426,C427,C428,C441,C443,C455,C456,
C544,C545,C433,C435,C442,C449,C450,C453,C
454,C457,C458,C461,C386,C387,C436,C451,C47
8,C479,C485,C491,C492,C498,C499,C505,C506,
C507,C42,C518,C519,C56,C70,C71,C72,R313
41
2CC1-10-C0G500-1
30J
R multi-layer chip
capacitor
1005, 13P±5%, 50V, C0G 2 C80,C268
42
5FE1-CB100505-10
2
SMD EMI filter 1005, 1KΩ [made in China] 24
FB17,FB20,FB41,FB42,FB43,FB3,FB44,FB45,FB
5,FB6,FB7,FB8,FB9,FB10,FB25,R38,FB13,FB14,
FB15,FB18,FB46,FB33,FB48,FB51
43
1IS1-XC6209F332
M
SMD voltage regulator
IC
3.3V, SOT-23-5 encapsulation, 300mA,
XC6209F332MR
2 IC15,IC8
44
3CR1-MM9329-270
0
STP RF coaxial
connector
SU:MM9329-2700, Mutata, -40°C-90°C 1 J4
45 2LL1-16-2N2SB Multi-layer chip inductor
1608, 2.2nH±0.3nH
(SDCL1608C2N2STDF), SunLord
1 L6
44
