DM588 Service Manual
SN
Material NO
Material Name
Specifications
QTY
Component NO
46 2LL1-16-22NJB Multi-layer chip inductor
1608, 22nH±5%
(SDCL1608C22NJTDF), SunLord
1 L7
47 2RS1-10-000O R chip resistor 1005, 0Ω 41
R21,R170,R171,R308,R309,R34,R140,R142,R76,
R86,R92,R137,R220,C358,R169,R326,FB21,FB2
2,FB23,R157,R179,R183,R184,R185,FB24,R186,
R187,R283,R284,FB34,FB35,FB36,FB37,R152,R
274,R275,R276,R300,C555,R272,R211
48
2RS1-10-120J
Chip resistor
1005, 12Ω±5%
2
R23,R74
49 1MR3-U10-U7-A GPS module
USTAR, U10-U7, 2.2-2.4mm high, lead
free
1 U1
50
2CC1-10-C0G500-1
50J
R multi-layer chip
capacitor
1005, 15P±5%, 50V, C0G 5 C101,C258,C286,C288,C452
51 2RS1-10-330J R chip resistor 1005, 33Ω±5% 25
R285,R286,R287,R288,R289,R290,R164,R165,R
166,R167,R168,R148,R149,R150,R151,R188,R18
9,R191,R207,R208,R209,R236,R237,R238,R324
52 2RS1-10-152J R chip resistor 1005, 1.5K±5% 1 R310
53
2CT1-TS32-160-3R
3M
R SMD Tantalum
capacitor
3216, 3.3μF±20%, 16V, TS series
(Encapsulation A)
2 C78,C113
54
2CC1-10-X7R500-3
32K
R multi-layer chip
capacitor
1005,3300P±10%,50V,X7R 3 C109,C160,C554
55
2CC1-32-X7R251-4
73K
Multi-layer chip
capacitor
3216,47nF±10%,250V,X7R,GRM31CR7
272E473K
1 C112
56
2CT1-TS32-350-R1
0M
SMD Tantalum
capacitor
3216, 0.1μF±20%, 35V, TS series
(Encapsulation A)
1 C114
57
2CC1-32-X7R500-1
02K
R multi-layer chip
capacitor
3216, 1000P±10%, 50V, X7R 1 C115
58
2CC1-10-C0G500-1
20J
R multi-layer chip
capacitor
1005, 12P±5%, 50V, C0G 10
C117,C118,C120,C146,C147,C187,C203,C211,C2
16,C228
59
2CC1-10-C0G500-1
R multi-layer chip
1005, 1.5P±0.25P, 50V, C0G
3
C119,C134,C470
45
