DM588 Service Manual
SN
Material NO
Material Name
Specifications
QTY
Component NO
74
1IS1-LMX2571NJK
T
Phase-locked loop IC
Brand: Texas Instruments; model:
LMX2571NJKT; encapsulation: 36PIN
WQFN
1 IC7
75
1TC1-UMC4
R SMD Darlington tube
UMC4, NPN/PNP
2
IC10,IC14
76
1IS1-OPA348
Operational amplifier IC
Model: OPA348; encapsulation: SC70-5
2
IC11,IC12
77 2LW1-25UC-471K
R SMD wire wound
inductor
2520, 0.47μH±10%, ceramic core
(FLM2520-R47K)
2 L8,L40
78 2LL1-16-1R0K
R multi-layer chip
inductor
SU:1608, 1μH±10% (MLF1608A1R0K) 2 L9,L15
79 2LW1-20UC-68NG
SMD wire wound
inductor
2012, 68nH±2%,
SAGAMI,C2012C-68NG
1 L10
80 2LW1-20UC-560G
SMD wire wound
inductor DP770-01
2012, 56nH±2%, [made in China]
(HWI0805UC56NG)
1 L11
81 2LW1-16UC-R33G
SMD wire wound
inductor
1608, 330nH±2% (C1608BR33G), lead
free
11
L12,L13,L14,L18,L19,L20,L50,L51,L56,L70,
L71
82 2LW1-20UC-470GA
R SMD wire wound
inductor
2012, 47nH±2%, ceramic core
(C2012C-47NG)
3 L16,L17,L68
83 2LW1-16UC-270J
R SMD wire wound
inductor
1608, 27nH±5%, ceramic core
(C1608CB-27NJ)
1 L21
84
1TT1-BFU550A
RF triode
BFU550A, SOT23 encapsulation, NXP
3
Q3,Q104,Q8
85 1TT1-2SC4617-R R SMD triode 2SC4617-R(BR), EMT3 1 Q4
86 1TT1-SSM3J15FS Switch triode SSM3J15FS, PMOS 1 Q5
87 1TT1-2SC5086 SMD triode Tube power amplifier, 2SC5086-O 3 Q7,Q13,Q14
88 2RS1-10-101J R chip resistor 1005, 100Ω±5% 7 R24,R25,R26,R27,R41,R49,R66
89 2RS1-10-6R8J Chip resistor 1005, 6.8Ω±5% 5 R30,R31,R33,R325,R328
90 2RS1-10-332J R chip resistor 1005, 3.3K±5% 1 R35
91
2RS1-10-181J
R chip resistor
1005, 180Ω±5%
2
R36,R44
92
2RS1-10-470J
R chip resistor
1005, 47Ω±5%
4
R37,R45,R111,R135
93
2RS1-10-121J
R chip resistor
1005, 120Ω±5%
1
R40
47
