Kirisun DM588 User Manual

DM588 Service Manual
SN
Material NO
Material Name
Specifications
QTY
Component NO
94
2RS1-10-392J
R chip resistor
1005, 3.9K±5%
4
R43,R46,R48,R108
95
2RS1-10-562J
R chip resistor
1005, 5.6K±5%
1
R47
96
2RS1-10-183J
R chip resistor
1005, 18K±5%
2
R50,R72
97
2RS1-10-273J
R chip resistor
1005, 27K±5%
1
R54
98
2RS1-10-124J
R chip resistor
1005, 120K±5%
2
R64,R129
99 2RS1-10-680J R chip resistor 1005, 68Ω±5% 1 R215
100
5OT1-12R8-ADL4-3
225
Temperature
compensated crystal
oscillator, VHF specific
(ENE3731A)
NDK, 12.8MHz±0.5ppm, Vc=0~3V, pull
range ±37ppm, -40℃~85℃, 3225
1 U9
101
2CC1-10-X7R160-4
73K
R multi-layer chip
capacitor
1005, 47nF±10%, 16V, X7R 1 C191
102
2CC1-32-C0G102-1
02J
R multi-layer chip
capacitor
3216, 1000P±5%, 1000V, C0G 3 C193,C200,C204
103
2CC1-32-C0G500-1
80J
Multi-layer chip
capacitor
3216, 18P±5%, 50V, C0G 1 C194
104
2CC1-32-C0G102-4
R0J
R multi-layer chip
capacitor
3216, 4P±0.25P, 1000V, C0G 1 C198
105
2CC1-32-C0G500-2
70J
Multi-layer chip
capacitor
3216, 27P±5%, 50V, C0G 2 C199,C209
106
2CC1-32-C0G102-2
20J
R multi-layer chip
capacitor
3216, 22P±5%, 1000V, C0G 1 C201
107
2CC1-32-C0G102-6
R0J
R multi-layer chip
capacitor
3216, 6P±0.25P, 1000V, C0G 2 C202,C196
108
2CC1-28-C0G1000-
180D
High-Q capacitor,
high-voltage
1111 encapsulation, 18pF 1 C205
109
2CC1-10-C0G500-2
20J
R multi-layer chip
capacitor
1005, 22P±5%, 50V, C0G 7 C206,C225,C242,C267,C360,C361,C362
110 2CC1-32-C0G500-1 Multi-layer chip 3216, 12P±5%, 50V, C0G 2 C207,C195
48
