DM588 Service Manual
SN
Material NO
Material Name
Specifications
QTY
Component NO
20J
capacitor
111
2CC1-10-C0G500-6
R0C
R multi-layer chip
capacitor
1005, 6P±0.25P, 50V, C0G 3 C210,C226,C300
112
2CC1-16-C0G500-4
71J
R multi-layer chip
capacitor
1608, 470P±5%, 50V, C0G 1 C602
113
2CC1-10-X7R500-1
83K
Multi-layer chip
capacitor
1005, 18nF±10%, 50V, X7R 1 C223
114
2CC1-10-C0G500-2
71J
Multi-layer chip
capacitor
1005, 270P±5%, 50V, C0G 1 C227
115 1DS1-JDP2S12CR R SMD switch diode JDP2S12CR (P1) 4 D14,D15,D16,D17
116 1DS1-RB706F-40 R SMD switch diode
Schottky barrier diode RB706F-40,
SOT-323
3 D31,D103,D20
117
1DR1-XBS053V15
R-1G
SMD Schottky barrier
diode
XBS053V15R-1G, SOD-523
encapsulation, VR=20V, VF=0.40V,
TOREX, lead free
1 D201
118 1IL1-NJM2904V SMD linear IC
Operational amplifiers NJM2904V and
TSSOP-8
1 IC13
119 2LL1-16-10NJA Multi-layer chip inductor
1608, 10nH±5%
(SDCL1608C10NJTDF), SunLord
2 L28,L30
120 2LW1-16UC-181J
SMD wire wound
inductor
1608, 180nH±5%, ceramic core
(C1608CB-R18J)
3 L29,L47,L27
121 2LW1-20UC-R18J
R SMD wire wound
inductor
2012, 180nH±5%, ceramic core
(C2012C-R18J)
1 L31
122 2LW1-16UC-270G
SMD wire wound
inductor
1608, 27nH±2%, ceramic core
(C1608CB-27NG)
1 L32
123
2LH1-R903R0-L05-
05
R SMD air core
inductor
Wire diameter φ0.9, inner diameter
φ3.0, 5-wind, 0.5mm high pin, reverse
winding
4 L33,L107,L108,L109
124 2LL1-16-47NGA Multi-layer chip inductor 1608, 47nH±2% (ELJRE47NGF) 5 L34,L35,L36,L42,L114
49
