DM588 Service Manual
SN
Material NO
Material Name
Specifications
QTY
Component NO
125
2LH1-R903R0-L03-
03
R SMD air core
inductor
Wire diameter φ0.9, inner diameter
φ3.0, 2.5-wind, reverse winding, lead
free
1 L113
126 2LW1-20UC-221J R SMD wire wound
inductor
2012, 220nH±5%, ceramic core
(LQN21AR22J/LQW2BHNR22J03L)
1 L316
127 1TT1-2SC3357 R SMD triode SU:2SC3357(RE), SOT89(NEC) 1 Q9
128 2RS1-16-103J R chip resistor 1608, 10K±5% 1 R22
129 2RS1-10-271J R chip resistor 1005, 270Ω±5% 4 R67,R91,R98,R99
130 2RS1-10-221J R chip resistor 1005, 220Ω±5% 6 R68,R69,R316,R317,R318,R319
131
2RS1-10-220J
R chip resistor
1005, 22Ω±5%
1
R71
132
2RS1-10-100J
R chip resistor
1005, 10Ω±5%
2
R79,R80
133
2RE1-10-1002
Precise SMD resistor
1005, 10K±1%
5
R81,R84,R85,R101,R15
134
2RE1-10-1004
R precise SMD resistor
1M 1005, 1M±1%
2
R82,R89
135 2RS1-10-222J R chip resistor 1005, 2.2K±5% 15
R83,R121,R125,R156,R190,R239,R240,R241,R1
7,
R299,R301,R302,R311,R312,R314
136 2RS1-16-101J R chip resistor 1608,100Ω±5% 2 R88,L53
137 2RS1-10-163J R chip resistor 1005 16K±5% 1 R93
138 2RS1-16-820J Chip resistor 1608, 82Ω±5% 2 R102,R104
139 2RE1-10-1003 Precise SMD resistor 1005, 100K±1% 1 R103
140 2TB1-TC4BMH
Balance-unbalance
converter (4BMH)
2:2:2, 100MHz-600MHz, insertion loss,
3.0max
2 BALUN5,BALUN6
141
2CC1-10-C0G500-2
21J
R multi-layer chip
capacitor
1005, 220P±5%, 50V, C0G 16
C240,C243,C247,C248,C256,C259,C263,C270,C
271,C274,C275,C278,C291,C459,C473,C474
142
2CC1-10-C0G500-1
60J
Multi-layer chip
capacitor
1005, 16P±5%, 50V, C0G 2 C284,C287
143
2CC1-10-C0G500-7
R0C
Multi-layer chip
capacitor
1005, 7P±0.25P, 50V, C0G 2 C285,C292
50
