Kirisun DM588 User Manual

DM588 Service Manual
SN
Material NO
Material Name
Specifications
QTY
Component NO
144
2CC1-10-C0G500-2
70J
R multi-layer chip
capacitor
1005, 27P±5%, 50V, C0G 2 C290,C302
145
2CC1-10-C0G500-3
90J
R multi-layer chip
capacitor
1005, 39P±5%, 50V, C0G 1 C301
146
2RS1-16-000O
R chip resistor
1608, 0Ω
3
L43,L55,L66
147 2LW1-20UC-270J
R SMD wire wound
inductor
2012, 27nH±5%, ceramic core
(C2012C-27NJ)
5 L2,L3,L4,L5,L41
148 2LW1-20UC-220J
R SMD wire wound
inductor
2012, 22nH±5%,ceramic core
(C2012C-22NJ)
5 L44,L45,L48,L49,L67
149 2LL1-16-15NJA Multi-layer chip inductor
1608, 15nH±5%
(SDCL1608C15NJTDF), SunLord
1 L46
150 2LI1-1608-R39G Radial choke inductor
0603, 390nH±2%, murata
LQW18ANR39G00
1 L52
151 2LL1-16-1R0KB Multi-layer chip inductor
1608, 1μH±10%
(SDFL1608Q1R0KTFB02), SunLord
1 L54
152 2LW1-16UC-271G
R SMD wire wound
inductor
1608, 270nH±2%, ceramic core
(C1608CB-R27G-RF)
1 L57
153 2LW1-16UC-180G
SMD wire wound
inductor
1608,18nH±2%, ceramic core
(C1608CB-18NG)
2 L58,L60
154 2LW1-16UC-680G
SMD wire wound
inductor
1608,68nH±2%, ceramic core
(C1608CB-68NG)
1 L59
155 2LL1-16-18NJA Multi-layer chip inductor
1608,18nH±5%(SDCL1608C18NJTDF),
SunLord
1 L72
156 1TT1-AT32011
Silicon bipolar
transistor
SU: Low power consumption, low noise,
NPN type, AT-32011, SOT-143
encapsulation; brand: AVAGO; lead free
1 Q12
157
1TT1-2SC5108-Y
SMD triode
2SC5108-Y (MC), NPN
3
Q15,Q16,Q28
158
2RS1-10-302J
R chip resistor
1005, 3K±5%
1
R110
159
2RS1-10-180J
R chip resistor
1005, 18Ω±5%
1
R112
51
