Kirisun DM588 - Page 68

DM588 Service Manual
SN
Material NO
Material Name
Specifications
QTY
Component NO
92
1TT1-2SC5086
SMD triode
Tube power amplifier, 2SC5086-O
4
Q6,Q7,Q13,Q14
93
1TF1-SSM3K15AF
S
R SMD field effect
transistor
SSM3K15AFS (D1) 3 Q10,Q20,Q11
94 2RS1-10-101J R chip resistor 1005, 100Ω±5% 9 R24,R25,R26,R27,R41,R45,R49,R62,R66
95 2RS1-10-6R8J Chip resistor 1005, 6.8Ω±5% 4 R30,R31,R33,R325
96 2RS1-10-332J R chip resistor 1005, 3.3K±5% 2 R35,R327
97
2RS1-10-121J
R chip resistor
1005, 120Ω±5%
3
R36,R40,R44
98
2RS1-10-822J
R chip resistor
1005, 8.2K±5%
4
R42,R55,R202,R218
99
2RS1-10-392J
R chip resistor
1005, 3.9K±5%
4
R43,R46,R48,R56
100
2RS1-10-562J
R chip resistor
1005, 5.6K±5%
2
R47,R108
101 2RS1-10-473J R chip resistor 1005, 47K±5% 8 R52,R119,R123,R226,R227,R153,R234,R18
102 2RS1-10-123J R chip resistor 1005, 12K±5% 3 R53,R221,R92
103 2RS1-10-273J R chip resistor 1005, 27K±5% 1 R54
104 2RS1-10-224J R chip resistor 1005, 220K±5% 2 R60,R161
105 2RS1-10-124J R chip resistor 1005, 120K±5% 1 R64
106 2RS1-16-473J R chip resistor 1608, 47K±5% 2 R335,R331
107
2RS1-16-563J
R chip resistor
1608, 56K±5%
1
R337
108
2RS1-16-222J
R chip resistor
1608, 2.2K±5%
1
R336
109
2RS1-10-680J
R chip resistor
1005, 68Ω±5%
1
R215
110
1TF1-RD01MUS2-5
01
ER SMD field effect
transistor (for portable
digital and analog
radios)
Mitsubishi, RD01MUS2-T513, packed in
tray, lead free
1 Q18
111
5XC1-16R8-6800CF
A
Crystal oscillator (for
models TP620, TP660,
DP585, DP580 and
DM588)
1XTV16800CFA, 16.8MHz 3225,
VC-TCXO, KDS
1 U9
112
2CC1-10-C0G500-4
R0C
R multi-layer chip
capacitor
1005, 4P±0.25P, 50V, C0G 5 C174,C246,C256,C300,C473
65
