DM588 Service Manual
SN
Material NO
Material Name
Specifications
QTY
Component NO
supply IC
84 1IS1-ADS1015 AD-to-IC converter
ADS105IRUGT, 10-Pin QFN
encapsulation, TI, lead free
1 IC2
85
1IS1-XC6209B552
MR
SMD voltage regulator
IC
TOREX,XC6209B552MR,SOT-25,-40~8
5°
1 IC3
86
1ID1-TS3A24159D
GSR
Single-pole
double-throw analog
electronic switch
TI,TS3A24159DGSR,SSOP-10，
5.05mm*3.10mm*1.1mm,-40 ℃
1 IC4
87
1TF1-TS5A3167DC
KR
Analogue electronic
transistor
TI,TS5A3167DCKR,SC-70,-~150 ℃ 2 IC6,IC22
88
1IS1-LMX2571NJK
T
Phase-locked loop IC
TEXAS
INSTRUMENTS,LMX2571NJKT,36PIN
WQFN,-40 to +85
℃
1 IC7
89
1IS1-XC6209F332
M
SMD voltage regulator
IC
TOREX,XC6209F332MR,SOT-25,-40~8
5°
2 IC8,IC15
90 1IS1-DAC104S085 DA converter chip
TEXAS
INSTRUMENTS,DAC104S085,VSSOP,-
40 to +125
℃
1 IC9
91
1TC1-UMC4
R SMD Darlington tube
Rohm,UMC4N,UMT5,-~150
℃
2
IC10,IC14
92 1IS1-OPA348
Operational amplifier
IC
TEXAS
INSTRUMENTS,OPA348,SC70-5,-40 to
+125 ℃
2 IC11,IC12
93 1IL1-NJM2904V R SMD linear IC JRC,NJM2904V,SSOP-8,-40 ℃ 1 IC13
94 1IM1-AK2365A FM demodulation chip
AKM,AK2365A,QFN-32，
4.0mm*4.0mm*0.7mm,-40
℃
to
1 IC17
95 1IS1-LT1901A-MCU
MCU + baseband
processing IC
LT1901A, for model S566 1 IC19
96
1DR1-TPD4S012D
TVS DIODE
TI,TPD4S012DRY,1.5mm*1.05mm*0.6
1
IC21
80
