DM588 Service Manual
SN
Material NO
Material Name
Specifications
QTY
Component NO
RY
mm,-40
℃ to 85℃
97 1IM1-AT24C512C SMD storage IC
atmel,AT24C512C,SOIC-8，
6.2mm*5.05mm*1.75mm,-40 ℃
1 IC23
98
1IS1-XC6209F502P
R
SMD voltage regulator
IC
TOREX,XC6209F502PR,SOT-89-5,-40
~85°
1 IC24
99 121I05000018 Active mixer PM210,3-6V, 1 IC26
100 3CF1-05-50P SMD FPC connector
50pin, spacing 0.5mm, flip-lock,
horizontal,
1 J3
101
2LG1-VLS3012ET-1
00M
SMD power inductor
TDK,VLS3012ET-100M,10,uH,±20%,3*
3*1.2
1 L1
102 2LL1-16-2N2SB
Multi-layer chip
inductor
SunLord,SDCL1608C2N2STDF,2.2,nH,
±0.3nH,1608
1 L6
103 2LL1-16-22NJB
Multi-layer chip
inductor
SunLord,SDCL1608C22NJTDF,22,nH,±
5%,1608
3 L7,L27,L29
104 2LW1-25UC-471K
R SMD wire wound
inductor
TOKO,FLM2520-R47K,0.47,uH,±10%,2
520
2 L8,L40
105 2LW1-16UC-R33G
SMD wire wound
inductor
sagami,C1608cB-R33G,330,nH,±2%,16
08
15
L9,L12,L13,L14,L18,L19,L20,L23,L24,L26,L56,L57
,L70,L71,R22
106 2LW1-20UC-150J
SMD wire wound
inductor
sagami,C2012C-15NJ,15,nH,±5%,2012 1 L10
107 2LW1-20UC-8R2J
SMD wire wound
inductor
2012,8.2nH±5%, ceramic core
(C2012C-8N2J)
1 L11
108 2LW1-16UC-181J
SMD wire wound
inductor
sagami,C1608CB-R18J,180,nH,±5%,16
08
4 L15,L47,L81,L80
109 2LW1-20UC-390GA
R SMD wire wound
inductor
2012,39nH±2%, ceramic core
(C2012C-39NG)
1 L16
110 2LW1-20UC-120GA
SMD wire wound
inductor
sagami,C2012C-12NG,12,nH,±2%,2012 1 L17
81
