Kirisun DM588 User Manual

DM588 Service Manual
SN
Material NO
Material Name
Specifications
QTY
Component NO
111 2LW1-16UC-120G
SMD wire wound
inductor
sagami, ceramic core
（C1608CB-12NG）,12nH±2%,1608,
5 L21,L32,L58,L60,L79
112 2LL1-16-4R7KA
Multi-layer chip
inductor
SunLord,SDFL1608Q4R7KTFB01,4.7,u
H,±10%,1608
1 L22
113 2LL1-16-1R0KB
Multi-layer chip
inductor
SunLord,SDFL1608Q1R0KTFB02,1,uH,
±10%,1608
2 L25,L54
114 2LL1-16-33NJA
Multi-layer chip
inductor
SunLord,SDCL1608C33NJTDF,33,nH,±
5%,1608
1 L28
115 2LW1-20UC-180G
SMD wire wound
inductor
murata,LQW2BAS18NJ00,18,nH,±5%,2
012
1 L31
116
2LH1-R903R0-L02-
03
R SMD air core
inductor
E20.90*3.0*1.5TR 5 L33,L107,L108,L109,L113
117 2LL1-16-27NJB
Multi-layer chip
inductor
SunLord,SDCL1608C27NJTDF,27,nH,±
5%,1608
4 L34,L35,L36,L114
118 2LW1-20UC-220J
R SMD wire wound
inductor
sagami,C2012C-22NJ,22,nH,±5%,2012 5 L44,L45,L48,L49,L67
119 2LL1-16-10NJA
Multi-layer chip
inductor
SunLord,SDCL1608C10NJTDF,10,nH,±
5%,1608
1 L46
120 2LI1-1608-R39G Radial choke inductor
murata,LQW18ANR39G00,390,nH,±2%
,0603
1 L52
121 2RS1-16-101J R chip resistor
yageo,RC0603JR-07100RL,100,Ω,±5%,
1608
2 L53,R330
122 2LL1-16-R47KB
Multi-layer chip
inductor
SunLord,SDFL1608LR47KTFB04,0.47,
uH,±10%,1608
1 L61
123 2LW1-35UF-472KB
SMD wire wound
inductor
,PIO32-4R7MT,4.7,uH,±20%,3.5*3.0*2.
1
2 L62,L63
124
2RS1-20-000O
R chip resistor
yageo,RC0805JR-070RL,0,Ω,±5%,2012
1
L68
125
2LH1-R501R5-R05-
05
SMD air core inductor E20.50*1.5*5TL 1 L69
82
