Kirisun DM588 User Manual

DM588 Service Manual
SN
Material NO
Material Name
Specifications
QTY
Component NO
0402
159 2RS1-10-822J R chip resistor
yageo,RC0402JR-078K2L,8.2,KΩ,±5%,
1005
4 R42,R55,R202,R218
160 2RS1-10-392J R chip resistor
yageo,RC0402JR-073K9L,3.9,KΩ,±5%,
0402
4 R43,R46,R48,R56
161 2RS1-10-562J R chip resistor
yageo,RC0402JR-075K6L,5.6,KΩ,±5%,
0402
1 R47
162 2RS1-10-123J R chip resistor
yageo,RC0402JR-0712KL,12,KΩ,±5%,0
402
3 R53,R92,R221
163 2RS1-10-224J R chip resistor
yageo,RC0402JR-07220KL,220,KΩ,±5
%,0402
3 R60,R161,R340
164 2RS1-10-124J R chip resistor
yageo,RC0402JR-07120KL,120,KΩ,±5
%,0402
1 R64
165 2RS1-10-390J chip resistor
yageo,RC0402JR-0739RL,39,Ω,±5%,04
02
1 R67
166 2RS1-10-151J R chip resistor
yageo,RC0402JR-07150RL,150,Ω,±5%,
0402
2 R68,R69
167 2RS1-10-220J R chip resistor
yageo,RC0402JR-0722RL,22,Ω,±5%,04
02
1 R71
168 2RS1-10-682J R chip resistor
yageo,RC0402JR-076K8L,6.8,KΩ,±5%,
1005
1 R72
169 2RS1-10-100J R chip resistor
yageo,RC0402JR-0710RL,10,Ω,±5%,04
02
2 R79,R80
170 2RE1-10-1002 Precise SMD resistor 1005,10K±1% 7 R81,R84,R85,R86,R101,R103,R222
171 2RE1-10-1003 Precise SMD resistor 1005,100K±1% 1 R82
172 2RS1-10-222J R chip resistor
yageo,RC0402JR-072K2L,2.2,KΩ,±5%,
0402
8 R83,R121,R125,R156,R190,R239,R240,R241
173 2RS1-20-101J R chip resistor
yageo,RC0805JR-07100RL,100,Ω,±5%,
2012
1 R88
85
