DM588 Service Manual
SN
Material NO
Material Name
Specifications
QTY
Component NO
145
1TF1-IRFR9024NP
BF
Power MOSFET IRFR9024NPBF,TO-252AA,-~150 ℃ 1 Q27
146 2RS1-10-103J R chip resistor
yageo,RC0402JR-0710KL,10,KΩ,±5%,0
402
36
R1,R7,R9,R28,R32,R39,R50,R51,R77,R109,R172
,R173,R175,R176,R177,R178,R192,R195,R197,R
200,R210,R214,R223,R224,R229,R230,R277,R27
8,R279,R291,R292,R293,R294,R315,R322,R323
147 2RE1-10-6802 Precise SMD resistor
yageo,RC0402FR-0768KL,68,KΩ,±1%,
0402
1 R3
148 2RE1-10-1602 Precise SMD resistor
YAGEO,RC0402FR-0716K2L,16.2,KΩ,±
1%,0402
1 R4
149 2RS1-10-102J R chip resistor
yageo,RC0402JR-071KL,1KΩ,±5%,040
2
13
R5,R6,R97,R127,R128,R144,R147,R182,R199,R2
01,R212,R233,R258
150 2RS1-10-472J R chip resistor
yageo,RC0402JR-074K7L,4.7,KΩ,±5%,
0402
3 R8,R232,R329
151 2RS1-10-273J R chip resistor
yageo,RC0402JR-0727KL,27,KΩ,±5%,0
402
3 R18,R54,R108
152 2RS1-10-473J R chip resistor
yageo,RC0402JR-0747KL,47,KΩ,±5%,0
402
8 R19,R52,R119,R123,R153,R226,R227,R234
153 2RS1-10-120J chip resistor
yageo,RC0402JR-0712RL,12,Ω,±5%,04
02
3 R23,R37,R74
154 2RS1-10-101J R chip resistor
yageo,RC0402JR-07100RL,100,Ω,±5%,
0402
9 R24,R25,R26,R27,R41,R45,R49,R62,R66
155 2RS1-10-104J R chip resistor
yageo,RC0402JR-07100KL,100,KΩ,±5
%,0402
17
R29,R57,R58,R59,R94,R106,R107,R115,R116,R1
55,R217,R228,R262,R264,R307,R338,R339
156 2RS1-10-6R8J chip resistor
yageo,RC0402JR-076R8L,6.8,Ω,±5%,1
005
4 R30,R31,R33,R325
157 2RS1-10-332J R chip resistor
yageo,RC0402JR-073K3L,3.3,KΩ,±5%,
0402
2 R35,R327
158
2RS1-10-121J
R chip resistor
yageo,RC0402JR-07120RL,120,Ω,±5%,
3
R36,R40,R44
84
