DM588 Service Manual
SN
Material NO
Material Name
Specifications
QTY
Component NO
203 2RS1-16-563J R chip resistor
yageo,RC0603JR-0756KL,56,KΩ,±5%,1
608
1 R337
204 2RS1-16-221J R chip resistor
yageo,RC0603JR-07220RL,220,Ω,±5%,
1608
1 R341
205 2RS1-16-823J R chip resistor
yageo,RC0603JR-0782KL,82,KΩ,±5%,1
608
1 R342
206 2RS1-10-561J R chip resistor
yageo,RC0402JR-07560RL,560,Ω,±5%,
0402
3 R345,R346,R347
207 1MR3-U10-H82-A
U10-H82 GPS/BD
model
USTAR,U10-H82 1 U1
208
5XC1-16R8-6800CF
A
Crystal oscillator KDS,16.8MHz,3225.0 1 U9
209 1IS1-LM2941S SMT IC
TEXAS
INSTRUMENTS,LM2941S,TO-236,-40
to +125
℃
1 U200
210
5XT1-MC146-32R7
6K
E SMD ceramic
resonator
EPSON,FC-135,-40 ℃～+85 ℃
1 X301
211
5OT1-26R0-HHL-03
03
Temperature
compensated crystal
oscillator
厦门屹新,26MHz±2ppm,3225.0
1 Y3
212 1IP1-0DM588-R01 DM588 Burning chip DM588 1 IC20
213 9FSO0000036
Software of model
DM588
DM588,V2.0.0.19 1
214
1IM1-TY8A0A11150
3KC
FLASH IC TY8A0A111503KC 1
215 6PM7-4291-HMD
DM588 Main board
PCB
138*85.8MM,DM588 main
board,1.6MM,6.0,FR4\
1
216 7MDC-4207-05A-W
Amplifier shield cover
(for model DP586)
Copper-Nickel-Zinc alloy, 0.2 mm thick,
square, 16.3*10.95*2; lead free,
7 V1,V2,V3,V4,V5,V6,V7
88
