DM588 Service Manual
SN
Material NO
Material Name
Specifications
QTY
Component NO
Chuanghong brand
217 7MDC-4207-04A-W
Power shield cover (for
model DP586)
Copper-Nickel-Zinc alloy, 0.2 mm thick,
square, 16.2*15.1*2.3; lead free,
Chuanghong brand
3 S1,S3,S4
218 7MDC-4207-01A-W
VCO shield cover (for
model DP586)
Copper-Nickel-Zinc alloy, 0.2 mm thick,
square, 31.05*13.3*3; lead free,
Chuanghong brand
3 P1,P2,P3
219 7MDC-4207-03A-W
Automatic power
control (APC) shield
cover (for DP586)
Copper-Nickel-Zinc alloy, 0.2 mm thick,
square, 21.3*11.45*2.2; lead free,
Chuanghong brand
1 Y1
220 7MDC-4072-08A-W STP-V shield cover 2
Material: Copper-Nickel-Zinc alloy,
T=0.2, 14.3*11.65*1.9, original color,
lead free, Junyu brand
1 X1
221
5XC1-50R0-49910
GQ9
Crystal oscillator
TP620 TP660 DP585
1D49910GQ9, 49.95MHz, 7*5, KDS 1 Z2
222
5FE1-BLM41P600S
PT
R SMD EMI filter
EMI,FILTER,
SMT,BLM41P600SPT,1206
2 L100,L101
223 3CR1-C88P132 RF coaxial connector C88P132-00001-H, 1 J4
224 1DV1-1SV278 R SMD varactor
TOSHIBA,1SV278,1.6mm*0.8mm*0.6m
m,-55
℃
to 125
℃
1 D13
225
6SS2-CON4073-BM
A
STM-U power
connector
Weld DM850 power socket and STM-U
power connection terminal
1 J302
226 3CP3-LCP200 DM850 power socket
LCP base, 2-pin, nickel plated brass
connector, lead free
1
227 7MBC-4073-01A-N STM-U power Nickel plated brass connector, lead free 2
89
