DM588 Service Manual
SN
Material NO
Material Name
Specifications
QTY
Component NO
9
2CC1-16-X7R500-104K
R multi-layer chip capacitor
1608, 100nF±10%, 50V, X7R
2
C32,C326
10
2CC1-20-X7R500-225K
Multi-layer chip capacitor
2012, 2.2μF±10%, 50V, X7R
1
C307
11
2CC1-10-X7R250-223K
R multi-layer chip capacitor
1005, 22nF±10%, 25V, X7R
3
C308,C518,C519
12
1DR1-NSR1020MW2T1G
SMD Schottky barrier diode
NSR1020MW2T1G, lead free
1
D1
13 1DR1-ESD9B5 TVS diode ESD9B5.0ST5G,5V, SOD923, lead free 10
D23,D24,D25,D26,D27,D28,D3
2,D33,D34,D35
14 5FE1-BLM11A601S R SMD EMI filter
1608, BLM11A601S/BLM18AG601S
(0138-05)
3 FB1,FB2,FB3
15 5FE1-CB100505-102 SMD EMI filter 1005, 1KΩ [Made in China] 1 FB4
16 3CM1-6PIN-135 SMD SIM card socket
H=1.35mm, drawer type, 6PIN,
SIM-6P13-011, lead free
1 J3
17 3CF1-05-50P SMD FPC connector
50-pin, spacing 0.5mm, flip-lock,
horizontal, Beijida brand
1 J6
18
1TF1-ST2301
R SMD field effect transistor
ST2301A, SOT-23
2
Q1,Q17
19
1TT1-DTC144EE
R SMD triode
Digital triode DTC144EE(26), SOT323
2
Q2,Q25
20 2RS1-10-471J R chip resistor 1005, 470Ω±5% 11
R1,R6,R7,R8,R9,R10,R11,
R18,R20,R25,R154
21
2RS1-10-472J
R chip resistor
1005, 4.7K±5%
8
R2,R3,R4,R5,R21,R22,R23,R24
22
2RS1-10-104J
R chip resistor
1005, 100K±5%
2
R19,R155
23 2CC1-32-X7R250-226K R multi-layer chip capacitor
22uF, 25V, X7R, 3216,±10%,
CL31A226KAHNNNE, SAM
1 C36
24 3CF1-FPC-05-20P SMD FPC connector socket
Beijida brand, spacing 0.5mm, 20-pin,
flip-lock bottom contact, 3U’’ gold
plating, edge connectors on double
faces
1 J5
25 6PD7-4291-EDC LCD board
DM588_FRONTBORAD_LCD_180529,
142X36X1.2MM, FR-4, 2-layer, lead free
1
26 2RS1-32-330J Chip resistor 3216, 33Ω±5% 1 R259
27 2RS1-10-000O R chip resistor 1005, 0Ω 3 R14,R15,R17
