Kirisun PT4200 User Manual

INSTALLING /REMOVING THE BATTERY PACK
4
3
*
resume the battery normal capacity.
Do not charge the battery again if it has been fully charged or it
is not in the low battery warning state, otherwise, its life will be
shortened or it will be damaged.
Take the battery away from the charger after charging.
If the battery is charged after all the power has been exhausted,
the red indicator will light about 1 minute later.
Match the guides of the battery pack with the
corresponding grooves in the bottom of the radio,
and insert the battery in.
Press downward the battery pack until the
release latch locks.
To remove the battery pack, push the release
latch upwards and then slide the battery pack
away from the radio.
Notice:
Do not short-circuit the battery terminals or dispose exhausted
battery in fire.
Do not disassemble the battery casing.
*
INSTALLING THE OPTIONAL
SPEAKER /MICROPHONE
INSTALLING THE ANTENNA
Screw the antenna into the connector at
the top of the radio by holding the
bottom of the antenna and turn it
clockwise until secure.
Insert the Speaker/Microphone plug into
the jacks of the versatile connector.
Note:
When use the optional Speaker/
Microphone, the radio will not be
waterproof.
Match the grooves of the belt clip with
those on the rear of the battery.
Then press the belt clip downwards to
lock it in place.
To remove the belt clip, use your nail or
a tool to lift the metal spring piece in the
belt clip from the topside, and then pull
the belt clip away from the radio.
INSTALLING /REMOVING
THE BELT CLIP
*
*
*
