Kirisun PT4200 User Manual

BASIC OPERATION
65
LED Indicator
Lights red while transmitting; lights green while receiving a signal.
Flashes red while in low battery power.
Channel Selector
Rotate to select channel 1-16.
Power/Volume Switch
Turn clockwise to switch on the radio.
Turn counterclockwise till a click is heard to switch off the radio.
Rotate it to adjust the volume after turning on the radio.
PTT (Push-to-talk)
To make a call, press and hold the PTT button, then speak into
the microphone in normal voice.
Release the PTT button to receive a call.
Monitor Button
Press to disable the SQUELCH, and enable the SQUELCH
again.
Channel Annunciation Button
Press it in standby state, and the channel number will be
annunciated. If press and hold this button, and at the same time
switch on the radio again, the type of voice annunciation of
1
2
3
4
5
6
7
8
channel number will be changed.
Emergency Button
Press and hold this button for over 2 seconds to activate warning
tone. Press it again to exit the emergency alert state.
Note:
When warning tone sounds, all of the buttons are disabled.
Microphone/Speaker Jacks
For connecting external Microphone/Speaker.
Switch On
Switch on the radio by turning the
Power/Volume switch clockwise till a click is
heard, then the radio will be in the state of
stand by and you will hear a beep if the dealer
has set it. And then you will hear voice
annunciation of the current channel number.
Adjust Volume
Press the monitor button to listen to the
background noise and rotate the Power/Volume
switch to adjust volume.
Select Channels
Rotate the channel selector to select channels.
You will hear voice from the speaker while
receiving proper signals.
If voice annunciation of channel number has
been set, the radio will annunciate the current
channel number.
